Send InquiryJY40Z Vertical Two-Roll Straightening Machine
Product Details:
- Product Type Other
- Technology Other
- Power Source Other
- Operating Type Semi Automatic
- Power 380 Volt (v)
- Surface Treatment Painted
- Dimension(L*W*H) 5.5X2.0X1.5 Meter (m)
- Supply Ability : 1000 Set Per Year
49000 USD ($)/Set
X
Price And Quantity
- 1 Set
- 49000 USD ($)/Set
Product Specifications
- Semi Automatic
- 380 Volt (v)
- 1000 Ton/day
- Painted
- Other
- 1 year
- Other
- make the black bars or bright bars straight
- 5.5X2.0X1.5 Meter (m)
- customized
- Other
Trade Information
- Qingdao
- Cash Against Delivery (CAD), Cash on Delivery (COD), Cash Advance (CA), Cash in Advance (CID), Cheque, Days after Acceptance (DA), Delivery Point (DP), Letter of Credit (L/C), Letter of Credit at Sight (Sight L/C), Telegraphic Transfer (T/T), Western Union, Paypal
- 1000 Set Per Year
- 2 Months
- Contact us for information regarding our sample policy
- seaworthy package
- Asia, Australia, South America, Middle East, Africa
- ISO9001, CE
Product Description
| Model | JY40Z | |||
| Workpiece required | Diameter range (mm) | Tensile strength σb≤450（Mpa） | Φ8~Φ40（L≥2000） | |
|
|
| Tensile strength σb≤1000 | Φ8~Φ38（L ≥2000） | |
|
| Surface hardness | ≤HB380（≤HRC42） | ||
|
| Straightness | ≤3 | ||
|
| Diameter tolerance | Bright steel≤IT10 | ||
|
| Roundness | ≤ 50% of diameter tolerance | ||
|
| Surface roughness | ≤3.2～6.3mm | ||
| Finished product | Straightness | ≤0.3 | ||
|
| Diameter tolerance | ≤IT8 | ||
|
| Surface roughness (Ra) | ≤0.8μm | ||
| Quantity of roll | 2 | |||
| Roll diameter (mm) | Φ200 | |||
| Straightening speed (infinite variable speed) | 2~14（m/min） | |||
| Main motor power (kW) | 30X2 | |||
| Lift motor power (kW) | 1.1 | |||
| Dimensions (m) | Host machine 5.5X2.0X1.5 | |||
| Total capacity (kW) | 50 | |||
| Source of compressed air (Prepared by the user) | 0.5~0.8MPaã€3m3/minã€with second grade oil-water separator | |||
